Zinco protective mat trimming SM-R roll 0.5 x 25 m, area approx. 320 g/m²
Protective mat strip made of polyester fibers designed for use in edge of roof / perimeter and connecting areas, particularly suitable for combination with Fixodrain® XD 20. Sprayed on the outside as an installation aid with pressure-sensitive adhesive; bitumen resistant, biological and biologically neutral; Thickness: approx. 3 mm; Weight: approx. 320 g/m².
gray, made of polyester fibers, strength factor 3, compatible with bitumen, rot-proof, water storage capacity approx. 3l/m², Thickness approx. 3 mm, one-sided with pressure-sensitive adhesive outside
| Order Nr.: | 2037 |
|---|---|
| Colour: | gray |
| Length [m]: | 25,0 |
| Material: | Polyester fibers |
| Width [mm]: | 500,0 |
| Thickness [mm]: | 3,0 |
| Packaging unit: | Role |
| Weight [g/m²]: | 320,0 |
| Geotextile strength class / strength factor: | 3 |
| Fire protection class: | b2 |
| Melting point [°C]: | 260,0 |
| Water storage capacity [l/m²]: | 3,0 |
| Compatible with bitumen: | Yes |
| Non-rotting: | Yes |
| UV-stabilized / protected against UV light: | no |
made of polyester fibers, grey, strength class 3, compatible with bitumen, rot-proof, water storage capacity approx. 3 l/sqm, Thickness approx. 3 mm, Weight approx. 320 g/m², Width approx. 50 cm, sprayed with pressure-sensitive adhesive on one-sided, deliver and install in the area of connections and terminations in such a way that the rising waterproofing areas are protected.
Product: Zinco protective mat trimming "SM-R"
Unit: m
Order Nr.: 2037
Installation should not be carried out if there is a risk of storms.
Installation:
The SM-R protective mat trimming is specially designed to protect rising structural elements when using Fixodrain® XD 20. It is laid loosely with approximately / approx. 10 cm overlapping along the edges of roof / perimeter and around roof penetrations. The SM-R is laid at least up to the top edge of the covering. On the roof surface, the trimming lies under the Fixodrain® XD 20. The SM-R protective mat trimming is sprayed with pressure-sensitive adhesive on the back as an assembly aid.
To protect against UV radiation and blowing away, the protective mat must be covered immediately after installation. Short-term protection against wind can also be provided by moistening the mats.
Cutting:
We recommend cutting the protective mat with sturdy universal scissors. When cutting, make sure that the waterproofing of the roof is not damaged under any circumstances! If damage does occur, it must be reported and repaired immediately.
The protective mat must be cut out in a circle over roof outlets, approximately / approx. 1 cm larger than the roof outlet all round (cross cutting is not sufficient!).
